รายละเอียดสินค้า
| Standard Sectional Dimension (mm.) | Unit Weight | Sectional Area | ||||
| A x B | t | r1 | r2 | kg./1 m. | kg./6 m. | cm.^2 |
| 18 x 18 | 2.30 | 4.00 | 0.63 | 3.80 | 1.13 | |
| 25 x 25 | 3.00 | 4.00 | 2.00 | 1.12 | 6.70 | 1.43 |
| 5.00 | 3.50 | 2.40 | 1.76 | 10.60 | 2.26 | |
| 30 x 30 | 3.00 | 4.00 | 2.00 | 1.36 | 8.20 | 1.73 |
| 5.00 | 5.00 | 2.40 | 2.18 | 13.10 | 2.78 | |
| 40 x 40 | 3.00 | 4.50 | 2.00 | 1.83 | 11.00 | 2.34 |
| 4.00 | 6.00 | 2.40 | 2.41 | 14.50 | 3.08 | |
| 5.00 | 4.50 | 3.00 | 2.95 | 17.70 | 3.76 | |
| 6.00 | 6.00 | 2.40 | 3.55 | 21.30 | 4.48 | |
| 45 x 45 | 4.00 | 6.50 | 3.00 | 2.74 | 16.44 | 3.49 |
| 5.00 | 6.50 | 3.00 | 3.38 | 20.28 | 4.30 | |
| 50 x 50 | 3.00 | 7.00 | 2.40 | 2.33 | 13.98 | 2.96 |
| 4.00 | 6.50 | 3.00 | 3.06 | 18.00 | 3.89 | |
| 5.00 | 6.50 | 3.00 | 3.77 | 23.00 | 4.80 | |
| 6.00 | 6.50 | 4.50 | 4.43 | 26.00 | 5.64 | |
| 60 x 60 | 4.00 | 6.50 | 3.00 | 3.68 | 22.00 | 4.69 |
| 5.00 | 6.50 | 3.00 | 4.55 | 27.00 | 5.80 | |
| 65 x 65 | 5.00 | 8.50 | 3.00 | 5.00 | 30.00 | 6.37 |
| 6.00 | 8.50 | 4.00 | 5.91 | 35.00 | 7.53 | |
| 8.00 | 8.50 | 6.00 | 7.66 | 46.00 | 9.76 | |
| 70 x 70 | 6.00 | 8.50 | 4.00 | 6.38 | 38.00 | 8.13 |
| 75 x 75 | 6.00 | 8.50 | 4.00 | 6.85 | 41.00 | 8.73 |
| 9.00 | 8.50 | 6.00 | 9.96 | 60.00 | 12.69 | |
| 12.00 | 8.50 | 6.00 | 13.00 | 78.00 | 16.56 | |
| 80 x 80 | 6.00 | 8.50 | 6.00 | 7.32 | 44.00 | 9.33 |
| 90 x 90 | 6.00 | 10.00 | 5.00 | 8.28 | 50.00 | 10.55 |
| 7.00 | 10.00 | 5.00 | 9.59 | 57.54 | 12.22 | |
| 10.00 | 10.00 | 7.00 | 13.3 | 79.8 | 17.00 | |
| 12.00 | 11.00 | 4.80 | 15.9 | 95.4 | 20.30 | |
| 13.00 | 10.00 | 7.00 | 17 | 102 | 21.71 | |
| 100 x 100 | 7.00 | 10.00 | 5.00 | 10.7 | 64.2 | 13.62 |
| 10.00 | 10.00 | 7.00 | 14.9 | 89.4 | 19.00 | |
| 12.00 | 12.00 | 4.80 | 17.8 | 106.8 | 22.70 | |
| 13.00 | 10.00 | 7.00 | 19.1 | 114.6 | 24.31 | |
| 120 x 120 | 8.00 | 12.00 | 5.00 | 14.70 | 88.20 | 18.67 |
| 130 x 130 | 9.00 | 12.00 | 6.00 | 17.90 | 107.40 | 22.74 |
| 12.00 | 12.00 | 8.50 | 23.40 | 140.40 | 29.76 | |
| 15.00 | 12.00 | 8.50 | 28.80 | 172.80 | 36.75 | |
| 150 x 150 | 12.00 | 14.00 | 7.00 | 27.30 | 163.80 | 34.77 |
| 15.00 | 14.00 | 10.00 | 33.60 | 201.60 | 42.74 | |
| 19.00 | 14.00 | 10.00 | 41.90 | 251.40 | 53.38 | |
| 175 x 175 | 12.00 | 15.00 | 11.00 | 31.80 | 190.80 | 40.52 |
| 15.00 | 15.00 | 11.00 | 39.40 | 236.40 | 50.21 | |
| 200 x 200 | 15.00 | 17.00 | 12.00 | 45.30 | 271.80 | 57.75 |
| 20.00 | 17.00 | 12.00 | 59.70 | 358.20 | 76.00 | |
| 25.00 | 17.00 | 12.00 | 73.60 | 441.60 | 93.75 | |
| 250 x 250 | 25.00 | 24.00 | 12.00 | 93.70 | 562.20 | 119.40 |
| 35.00 | 24.00 | 16.00 | 128.00 | 768.00 | 162.60 | |
